Valve Tester MKII

Tax included.

Low stock

Free Worldwide shipping
UK delivery within 1-3 working days
Your right to repair
Legendary Orange manufacturing

Automatically tests Hi-Fi/guitar amplifier valves and displays their condition, performing a wide range of tests, quickly and accurately.

Specification

Style

Test equipment

Expansion modules currently available

3000B
EF86
GZ34
EZ80
6SN7

Testing valves

EL34
6CA7
6L6
6V6
6V6GTA
KT66
KT77
KT88
KT120
6550
5881
EL84
6BQ5
ECC81
12AT7
ECC82
12AU7
ECC83
12AX7
12BH7

Weight

1.56 kg / 3.44 lb

Dimensions (W x D x H)

17.6 x 16.2 x 6.8 cm
6.9 x 6.4 x 2.7 in

Included in box

1 x Valve Tester MKII
1 x power supply
1 x mains lead
1 x manual
1 x pencil

Test sequences

Heater filament test: Short circuit
Heater filament test: Open Circuit
Heater filament test: Tolerance check
Heater cathode insulation: Leakage
Heater cathode insulation: Short Circuit
Test for heater current abnormalities
Amplification factor
Voltage gain
Power gain
Screen grid test
Mutual conductance test
Dual test for double triodes
Emission
Inter Electrode leakage
Inter electrode short circuit
Flash-over (arc detection, high voltage breakdown)
Gas ionisation test
New thermal runaway test
New enhanced grid leakage detection test

Additional features

New microphony function test (please note : The microphony function test is for ECC81, ECC82, ECC83 & 12BH7 valves only)
Capability to test directly heated valves with expansion modules
All valves tested under higher current
Improved test sockets
More rugged design
Capability to test other valve types such as rectifiers with expansion modules
Valve failure mode fault indication

Please note: when removing valve from the tester, please hold the bottom of the valve as the tester could be hot.

Shipping information

Orders received before midday will be dispatched same day, with overnight delivery in the UK
Orders received after midday will be dispatched the next day, with overnight delivery in the UK

Returns policy

Please see our full returns policy here.

Designed & Made in the UK

The Orange Valve Tester MKII, proudly crafted and engineered in the UK, revolutionises valve-testing technology. With seamless precision and simplicity, it effortlessly conducts a comprehensive array of tests, setting a new global standard for both Hi-Fi enthusiasts and service professionals.

Complexity made simple

The simplicity of operation belies the complexity of what happens inside the unit during each test. Inside is a sophisticated microprocessor controlled testing system carrying out a series of complex inter-electrode switching and measurement exercises. Requiring no knowledge of valve theory a user simply inserts a valve into the correct socket, selects the valve type from the list and presses the OK button. The status of the valve under test is quickly revealed.
Portable and Convenient

The Orange Valve Tester MKII is a sophisticated, simple to use, stylish and portable unit. Its usefulness has been designed to meet the needs of both seasoned audiophiles and those new to testing valves. The device’s fully automatic testing and matching capabilities ensure optimal valve performance across a wide range of audio valve equipment allowing users to effortlessly maintain quality, maximum performance and limit possible distortion of their Hi-Fi amplifier caused by substandard, worn or faulty valves.
New and Improved

The latest model of the Orange Valve Tester has greatly improved algorithms with an updated database containing the test results of literally hundreds of new, used and faulty valves giving the MKII a much greater intelligence compared to the original Orange VT1000. All the voltages required by the tester are internally derived, stabilised and controlled allowing a rapid static and transient testing without unnecessary heat generation.

Expansion Modules Available

Plug-in expansion module for the Valve Tester MKII

Tax included.

Orange Valve Tester mk2

I found the tester really easy to use and it helped quickly identify microphonics in a batch of old tubes I had, I could easily check power valves pairing, and identify those 'hotter' pre-amp tubes.

The only reason for giving four stars is the price - but these aren't going to be sold in large volumes, and if you test enought valves, or have multiple amps, it's worth the investment.

Hi Michael,

Thank you for taking the time to leave us a review - we really appreciate it!

Valve Tester Mk2

Like all Orange gear it’s exactly as expected and this valve tester is easy to use, fast process of the test within a cpl mins, outstanding. Another great use , I will be taking is compact unit with me whenever purchasing Valves from a private seller ( unused vintage stocks of Hi-Fi tube collectors that need to sell )& get a value/rating without concerns or relying solely on faith. Got some great 1970’s tubes , unused and 1/3 price of new issues. 👍👍 from me.

Thanks so much for taking the time to leave us a review - we really appreciate it Mark! Glad to hear you're loving your Valve Tester.

Valve tester

I haven't had much chance to use it but checked all the valves I have here at home. Service was great. It arrived so fast I was wondering what it was.
I got all the valves matched up now that's a great feature

Hey Carter, thanks so much for taking the time to leave us a review - we really appreciate it! Glad you were happy with the speedy delivery :)

Valve Tester MkII

Excellent tube tester. Wish there were more tube options to choose from though.

Thanks for your feedback Robert - we really appreciate you!

Extremely Useful!

The Orange Amplifiers Valve Tester MKii is an innovative and highly anticipated upgrade from its predecessor, designed to meet the needs of both professional musicians and amp technicians. With its user-friendly interface, enhanced functionality, and robust build quality, this new valve tester promises to set a new standard in tube testing!

Hey Quincy, we're so glad you're finding the Valve Tester useful! Thank you for taking the time to leave a review - we really appreciate it.
